Seitron control unit for gas leak sensors 4 IN 2 OUT + RESET RGI000MSX4

4-in-2-out + Reset control unit for gas leak detectors with 4 inputs. Alarm status memory. Reset and test buttons, and 2 relay outputs.

TECHNICAL SPECIFICATIONS
Power supply 230V~ -15/+10% 50Hz
Output (relay) 2x6(2)A @ 250V~ SPDT
Indications: active/fault/alarm 4 green LEDs/flashing LED/4 red LEDs
Delay on solenoid valve relay 1 .. 90 sec.
Button 1 Test
Button 2 Reset
Protection rating IP54
Dimensions H188 W230 D114mm
