Rothenberger - ROCADDY 120, R32 CL digital - 1000003623

Refrigerant recovery unit for R32 and other gases

The Rothenberger ROCADDY 120, R32 CL digital (code 1000003623) is a professional recovery unit specifically designed to handle A2L flammable refrigerants like R32, in addition to traditional refrigerants. This all-in-one system combines efficiency, safety, and convenience for refrigeration and air conditioning professionals.

Key technical features

The ROCADDY 120 unit is equipped with a high-performance oil-less compressor that ensures high recovery rates of up to 0.5 kg/min, significantly reducing service times. The system is certified to operate with A2L flammable refrigerants (such as R32) and traditional refrigerants, offering maximum operational versatility. The device includes a digital electronic scale with ±10g accuracy for precise control of the recovered refrigerant quantity.

Advanced safety for flammable refrigerants

Designed according to the latest safety regulations, the ROCADDY 120 incorporates explosion-proof components and protected circuits to operate safely with flammable refrigerants like R32. The automatic pressure control system prevents dangerous overpressures, while integrated sensors constantly monitor operating conditions. The calibrated safety valve intervenes automatically in case of anomalies, ensuring maximum protection during operations.

Practical and functional design

The ROCADDY 120 features a compact and robust design with an integrated trolley for easy transport to the job site. The digital control panel offers an intuitive interface with a backlit LCD display that shows pressure, temperature, and recovered refrigerant quantity in real-time. The high and low-pressure gauges are protected from accidental impacts thanks to the reinforced structure. The system also includes integrated storage compartments for hoses, adapters, and accessory tools.

Professional applications

This recovery unit is ideal for:

• Maintenance and repair of domestic and commercial air conditioning systems
• Interventions on heat pumps using R32
• Retrofitting old systems with new refrigerants
• Refrigerant recovery during system decommissioning
• Scheduled maintenance of HVAC systems in industrial settings

Detailed technical specifications

The system operates with a wide range of refrigerants including R32, R410A, R134a, R22, R407C, and others. The recovery capacity varies from 0.3 to 0.5 kg/min in liquid phase and 0.2-0.3 kg/min in vapor phase. Power supply: 230V/50Hz with a power consumption of 550W. The digital scale has a maximum capacity of 120 kg with an accuracy of ±10g. The achievable ultimate vacuum is 0.5 mbar. Operating temperatures: 5°C to 40°C. Dimensions: 480 x 370 x 630 mm. Weight: 18 kg.

Included equipment

The supply includes:

• ROCADDY 120 R32 CL digital base unit
• Digital electronic scale
• Set of 1.5m reinforced hoses (blue and red)
• Adapters for different connection types
• Replaceable filter drier
• Complete instruction manual
• Certificate of conformity for A2L refrigerants

Maintenance and support

The ROCADDY 120 is designed for long life with minimal maintenance. The filter drier is easily replaceable without special tools. Rothenberger offers dedicated technical support and original spare parts through its network of authorized centers. The standard warranty covers 24 months for manufacturing defects, extendable according to the manufacturer's policies.
